FP581 equalisation cable 13,257 mm for Kroemer FP42

Extra-long 13,257 mm equalisation cable for Kroemer FP42 4-post lift – FP581

The FP581 equalisation cable is a suitable spare part for the Kroemer FP42 4-post lift. It is routed through the designated cable guide and supports the even movement of the runways when raising and lowering the lift.

The Kroemer FP42 uses a total of four equalisation cables of different lengths. These are classified according to their length as short, medium, long and extra-long. This item is the extra-long equalisation cable with an overall length of 13,257 mm and a cable diameter of 9.53 mm.

During regular operation, the steel cable is continuously exposed to mechanical loads. Corrosion, broken individual wires, deformation or other visible signs of wear may impair reliable cable routing and the even movement of the lift. Timely replacement of the affected equalisation cable supports the professional repair and reliable operation of the FP42.

The other equalisation cables for the Kroemer FP42 in short, medium and long versions can be found below this product description in the Accessories section. The three other cable lengths are linked there as separate spare parts.

Product features

• Extra-long equalisation cable for the Kroemer FP42 4-post lift
• One of four equalisation cables of different lengths
• Version: extra-long
• Supports the even movement of the runways
• Suitable for the professional repair of the cable routing
• Robust steel cable for regular workshop use

Technical specifications

• Item number: FP581
• Product type: equalisation cable
• Compatible model: Kroemer FP42
• Version: extra-long
• Length: 13,257 mm
• Cable diameter: 9.53 mm
• EAN: 0703441936456

Scope of delivery

1 FP581 equalisation cable – version: extra-long
Length: 13,257 mm

Important application note

Before ordering, carefully check the lift model, item number and length of the existing equalisation cable. As the FP42 is fitted with four equalisation cables of different lengths, the short, medium, long and extra-long versions must not be confused with one another.

A serial number or identification marking is located at both ends of the equalisation cable. This provides information about the version and generally also includes the cable length, often at the end of the marking. Compare this information with the existing cable to clearly identify the correct spare part.

The short, medium and long equalisation cables for the FP42 can be found below the product description in the Accessories section.

Replacement, tensioning and adjustment of the equalisation cable must only be carried out by qualified personnel when the lift is fully lowered, switched off and secured against unintentional activation. After installation, the cable routing, fastenings, cable tension and even lifting movement must be checked carefully.
