FP578 equalisation cable 7,218 mm for Kroemer FP42

Short 7,218 mm equalisation cable for Kroemer FP42 4-post lift – FP578

The FP578 equalisation cable is a suitable spare part for the Kroemer FP42 4-post lift. It runs through the designated cable routing and supports the even movement of the runways when raising and lowering the lift.

The Kroemer FP42 is fitted with a total of four equalisation cables of different lengths. These are classified as short, medium, long and extra-long equalisation cables. This item is the short equalisation cable with an overall length of 7,218 mm. One cable of this version is required per lift.

During regular operation, the steel cable is continuously exposed to mechanical loads. Corrosion, damaged individual wires, deformation or other signs of wear may impair the cable routing and the even movement of the lift. Timely replacement supports reliable operation and the professional repair of the FP42.

The equalisation cable has a diameter of 9.53 mm and is supplied individually. The other FP42 equalisation cables in medium, long and extra-long versions can be found below this product description in the accessories section. The corresponding cable lengths are linked there as separate spare parts.

Product features

• Short equalisation cable for the Kroemer FP42 4-post lift
• One of four equalisation cables of different lengths
• Version: short
• Supports the even movement of the runways
• Robust steel cable for regular workshop use
• Suitable for the professional repair of the cable routing
• One equalisation cable of this length is required per FP42

Technical specifications

• Item number: FP578
• Product type: equalisation cable
• Compatible model: Kroemer FP42
• Version: short equalisation cable
• Length: 7,218 mm
• Cable diameter: 9.53 mm
• EAN: 0703441936425

Scope of delivery

1 FP578 equalisation cable – version: short
Length: 7,218 mm

Important application note

Before ordering, carefully check the lift model, item number and length of the existing equalisation cable. As the FP42 is fitted with four equalisation cables of different lengths, the short, medium, long and extra-long versions must not be confused with one another.

A serial number or identification marking is located at both ends of the equalisation cable. This provides information about the cable version and generally also includes the cable length, often at the end of the marking. Compare this information with the existing equalisation cable to clearly identify the correct spare part.

The medium, long and extra-long equalisation cables for the FP42 can be found below the product description in the accessories section.

Replacement, tensioning and adjustment of the equalisation cable must only be carried out by qualified personnel when the lift is fully lowered, switched off and secured against unintentional activation. After installation, the cable routing, fastenings, cable tension and even lifting movement must be checked carefully.
