Half Automatic 4 Post lift "Oxford" 3.6h - Parking lift

Special features of "Oxford" FP42

• 1A processing quality, with CE certificate for APR acceptance

• Production according to ISO 9001

• Signal tone and CE-Stop when lowering to prevent crushing in the foot area (foot trapping protection)

• extra flat, removable ramps

• 4 removable vehicle roll-stops

• manual unlocking and safety grid against unintentional lowering of the lift

• foot protection

• extraordinarily flat drive-over height of 125 mm

• Maximum passage width for the vehicle parked on the ground: 2370 mm

• Maximum track width of the vehicle above: 2020 mm

• Maximum passage width for the vehicle standing on the lifting platform: 2280 mm

• Audible alarm and emergency stop button

• Rope breakage protection and slack rope

• Mechanical safety catches

• Powder-coated finish, with a scratch-resistant surface

• Convenient control box (protection class IP54 and 24 V control voltage)

• Hydraulic cylinders under the runway for powerful lifting

• Hydraulic overload valve

• Overload protection by means of a pressure relief valve

--- IMPORTANT NOTICE ---  During the unloading, the customer must have a forklift available

With a maximum lifting height of 2.18m and a powerful 24V control unit as well as heavy-duty ramps, work in the workshop has never been easier. The maximum lifting height of up to 2,185 allows for problem-free parking under the platform. This means that larger vehicles such as SUVs can also be parked under the lifitng platform.

The FP42 "Oxford" 4-post lift is capable of lifting a maximum weight of 3,600 kg. Therefore, the FP42 "Oxford" should urgently be fixed to the ground to ensure safety and stability when lifting your vehicles.

4 plastic drip trays and one metal oil tray are optionally available. Krömer ensures that nothing goes wrong in the future.

With this model, our "Krömer Easy Angles" can also be ordered as an option for €69. With the help of these practical offset plates, the hydraulic motor and control panel can be rotated at a 90° angle around the main column. It is thus possible for you to accommodate several lifts in less space or to mount the columns close to the wall.

We also offer an optional axle-free jack for the FP42 lift for €599. Changing a wheel should therefore not be a problem on the 4-post lift.

No more scratches on the paintwork and poor processing: Your new 4-post lift from Krömer has a powder-coated paintwork. In addition, the ramps on the platform are painted in RAL 7016.

Of course, this model also comes to you with the comprehensive Krömer guarantee, because the 4-post lift FP "Oxford" has been tested in accordance with the Machinery Directive in accordance with Annex IV with a type examination and was therefore manufactured in accordance with ISO and CE regulations. This is how you succeed in the APR acceptance with distinction. If something should stop working, we always have the right spare part ready for you.

We have Allianz product liability insurance and business liability insurance on our products! Sadly, this is not the case for the most of our competition which displays their attitude towards their customers.

For the first start-up you need hydraulic oil of the DIN type HLP 46 (12 liters required). Before operation, the operator's manual, the concrete foundation plan and the operation and maintenance manual must be worked through. Electrical work must be carried out by appropriately authorized specialist personnel.

* additional hand pump is required to release the lift from the safety catch

Not eligible for express shipping

Scope of Delivery

• KRÖMER 4-post lift FP42 "Oxford"
• Electric motor 230V or 400V hydraulic unit
• German operating manual and inspection log for UVV inspection available for download in our FAQs or instructions and inspection log
• Heavy-duty anchors (12 pieces)
• Mobile chassis system

Not included in the delivery

• Oil – optionally available for separate order (filling volume: 15 liters)
• Vehicle

Unloading information

Despite the high-quality paint finish, minor scratches may occur during logistics handling, quality control, or assembly.
