Double Scissor Lift "Belfast"

  • suitable for retractable construction
  • Usefull lifting height up to 200 cm
  • Lifting time is 50 seconds
  • Has a remote control if necessary
  • Acoustic warning device (foot protection)
  • Built-in steering aid
  • Control panel with folding fuses instead of glass fuses
  • Built-in LED light and steering aid
  • a compressor with 8-10 bar is required to unlock
Availability: Out of stock
Only %1 left
More Information
Delivery Time 5-10 Business days
Shipping Cost 399 €

Specialities of Scissor Lift "Belfast"

  • Hydraulic with air compressor
  • Two-wall compressed air cylinder
  • Low-noise operation due to modern motor
  • DUPONT®-paint layer
  • 2000 mm lifting height
  • 4-fold extendable vehicle mounts
  • Lockable drive-on ramps can each be loaded with 800 kg per side
  • Powerful aluminum electric motor with IP 54 control unit + aluminum hydraulic motor + metal oil tank
  • Signal tone and CE-Stop when lowering to prevent crushing in the foot area (foot trapping protection)
  • Overload protection by means of a pressure relief valve
  • Safety locking system with pneumatically unlockable mechanical safety latch against unintentional lowering of the lift

With a maximum lifting height of an huge 2000 mm and a lifting time of a rapid 50 seconds, a Krömer scissor lift is a must for almost all maintenance work on tires and lower body parts.

Especially in the commercial work area such as in workshops or tire services, special requirements are placed on lifting platforms. We at Krömer are informed about those problems and therefore offer you our specially adapted professional scissor lifts.  The ambitious hobbyists trust the XX61 as well, due to reason that it can be installed countersunk (for 0 mm drive-over height).

Does your car have a longer wheelbase? No problem for Kromer! Due to its 4x extendable, extra large (2,115 x 540 mm) drive-on ramps, your new professional scissor lift is extremely flexible. This will lift even the Porsche of your most demanding customer in a matter of seconds. With a new reinforcement of the movable scissors, this stage is also ideally suited for SUV areas.

Our engineers have specially designed this professional scissor lift for long periods of operation. Grease nipples were installed on almost all moving joints. One of the most common sources of failure in scissor lifts are corroded air lift cylinders. Krömer products therefore have an oiler as standard, which is used to remove water from the compressed air circuit. Another weak point of conventional platforms are leaking hydraulic cylinders. At Krömer you can get our special double-wall compressed air cylinder as an option. This lowers the mid rise scissor lifts susceptibility to errors and at the same time reduces the maintenance intensity.

Low-noise operation also due to the motor! Since the newly designed engine is completely immersed in oil, it is extremely quiet! Easy on the ears with daily use.

Low-noise operation also due to the motor! Since the newly designed engine is completely immersed in oil, it is extremely quiet! Easy on the ears with daily use

At Krömer, we don't have our hard-chromed hydraulic cylinders manufactured in a backyard workshop, which is reflected in the lower susceptibility to errors and the lower maintenance intensity. If something should stop working, we always have the right spare part ready for you.

More Information
SKU XX61
EAN-Code 0757284116643
Write Your Own Review
You're reviewing:Double Scissor Lift "Belfast"
Your Rating

Krömer Doppelscherenhebebühne XX61
OPTIONAL: Komplettes Krömer Fahrwerk (Mobilkit)
E-Motor 230V oder 400V Hydraulik Einheit
Deutsche Bedienungsanleitung und Prüfbuch für die UVV Abnahme als Download in unseren FAQ's oder hier Anleitung und Prüfbuch
4x Gummiklötze als Unterlage
