2-Post Fully Automatic Lift Kroemer TP22
In stock
- Delivery time:
- Shipping cost:
- Automatic safety lock release
- 2-stage and 3-stage telescopic lifting arms
- Drive-over plate only 33 mm high, including cable duct to protect the hydraulic lines and synchronisation cables
- Minimum arm height: 100 mm
- Double safety system for the arm locking mechanism
- Lifting and lowering time: 44 seconds
- 230 V socket on the control panel
- Lifting capacity: 4.2 tonnes
Description
Kroemer TP22 2-post lift – 4,200 kg lifting capacity, fully automatic unlocking & flexible lifting arms
Upgrade your workshop with our premium 2-post lift, specially designed for maximum stability, safety and efficiency. This advanced lifting system takes your workshop to the next level – ideal for professionals who value quality, durability and reliable performance.
Why this lift is the right choice
Outstanding stability and durability
Premium support columns: Manufactured from special rolled profiles and robust Q235 steel, our support columns provide exceptional stability and safety.
High-quality components: The M16 synchronisation cable (instead of the commonly used M12) and wear-resistant hydraulic hoses ensure an impressive service life of up to 20,000 lifting cycles. We offer a 5-year warranty on the wear-resistant hydraulic hoses, giving you long-term reliability and dependable performance.
Innovative coating: Our wear-resistant paint finish, developed on the basis of 20 years of experience and using high-quality Teflon wax, offers excellent durability and quality compared with conventional powder coatings.
Maximum safety
Certified quality: Our lift complies with strict CE standards and is manufactured in accordance with ISO 9001. The integrated 4-point safety system, automatic safety locks and emergency lowering function in the event of a power failure provide a high level of safety for both the operator and the vehicle.
Powerful hydraulics: The two oversized hydraulic cylinders enable smooth lifting and lowering of heavy vehicles. The powerful 2.2 kW aluminium motor is particularly suitable for vehicles weighing 2.5 tonnes and above.
Flexibility for a wide range of vehicles
Versatile lifting arms: The 2-stage and 3-stage telescopic lifting arms are suitable for a wide range of vehicle types, including lowered sports cars. The CE-tested locking system ensures secure vehicle lifting.
Precise adjustment: Integrated screw-adjustable lifting pads and rotating platforms with double threads provide maximum flexibility and precise adjustment to different vehicle lifting points.
High-quality electrics and practical accessories
Durable electrical system: Our 2-post lift is equipped with a modern and durable electrical system. The new Anti-Lift-Up button enables precise lowering of the lift, while an integrated 230 V socket provides additional convenience in everyday workshop use.
Accessories included: The scope of delivery includes heavy-duty anchors and durable rubber pads for the lifting arms. Hydraulic oil and the II501 motor cover can also be ordered separately as optional accessories.
Optional accessories:
Hydraulic oil (15 litres) – optionally available
Power cable and plug – optionally available
TP004 floor reinforcement plates – optionally available
Below the product description, you will find an extensive accessories section with a wide selection of products and services for the TP22.
Invest in a high-quality solution for your workshop and benefit from outstanding performance, quality and safety.
Technical Data
Technical Data
| SKU | TP22 |
|---|---|
| EAN-Code | 0703441952517 |
| Delivery Time | 15 business days |
| Shipping costs | 599 £ |
| Suitable for express delivery | No |
| Lifting height max. | 1.900 mm |
| Säulenabstand | 2830 mm |
| Carrying Capacity | 4.200 kg |
| Clearance height | 30 mm |
| Weight | 650 kg |
| Einschwenkhöhe | 100 mm |
| Netzfrequenz | 50 Hz |
| Operating voltage | 230V oder 400V |
| Motor power | 2,2 kW |
| Geräuschepegel | < 70 dB(A) |
Delivery Scope
Delivery Scope
Not eligible for express shipping
Scope of Delivery
- 2-post vehicle lift 4.2t Kroemer TP22
- Electric motor 230V (available again from early August) or 400V hydraulic unit
- Support arms
- Column covers
- German operating manual and inspection log for UVV inspection available in DOWNLOADS
- Invoice with VAT shown.
Not included in the delivery
- Oil – optionally available for separate order (filling volume: 15 liters)
- Power cable + plug
- Heavy-duty anchors: The selection of suitable approved anchor systems must be carried out on-site according to the foundation design, concrete quality, component thickness, edge and axial distances, as well as the loads occurring.
- Base reinforcement plates TP004
- Vehicle
Unloading information
Despite the high-quality paint finish, minor scratches may occur during logistics handling, quality control, or assembly.
